performance characteristics
1. using german host technology for reference, all copper wire winding has small starting current, which can reach 2.0mpa.
2. the piston sleeve is made of graphite high-pressure casting, with high temperature resistance and self-lubricating function. the piston is made of peep imported material, and the high temperature resistance exceeds 500 ℃;
3. double cylinder balanced compression, small vibration, low noise, main engine force balance
4. adopt imported skf double row self-aligning high-pressure bearing, optimize the contact design between the large end face of roller and the guide surface of large flange, and the bearing always works under constant temperature;
host parameter table
|
model
|
jp2v-d50
|
jp2v-d55
|
jp3w-d60
|
jp4v-d50
|
jp4v-d55
|
jp6w-d60
|
|
exhaust volume (m³/min)
|
0.1
|
0.17
|
0.2
|
0.2
|
0.32
|
0.4
|
|
exhaust pressure (mpa)
|
0.8-1.0
|
0.8-1.0
|
0.8-1.0
|
0.8-1.0
|
0.8-1.0
|
0.8-1.0
|
|
motor power (kw)
|
1.1kw
|
1.5kw
|
2.2kw
|
2.2
|
3.0
|
4.0
|
|
rated voltage (v)
|
220
|
220/380
|
220/380
|
220/380
|
220/380
|
380
|
|
frequency (hz)
|
50
|
50
|
50
|
50
|
50
|
50
|
|
rated speed (r/min)
|
1440
|
1440
|
1440
|
1440
|
1440
|
1440
|
|
noise (db（a）)
|
65
|
75
|
80
|
76
|
78
|
80
|
|
net weight (kg)
|
26
|
28
|
40
|
48
|
49
|
60
|
|
overall dimension: l * w * h（mm）
|
420*370*400
|
420*370*400
|
500*360*390
|
570*370*400
|
570*370*400
|
700*360*390
|
