location：home > products > abdominal suction oil free air compressor > complete machine series


complete machine parameter table

model jp2v-50 jp2v-55 jp3w-60 jp4v-50 jp4v-55 jp6w-60
exhaust volume ( m³/min ) 0.1 0.17 0.2 0.2 0.32 0.4
exhaust pressure ( mpa ) 0.8-1.0 0.8-1.0 1.0 0.8-1.0 1.0 1.0
motor power ( kw ) 1.1kw 1.5kw 2.2kw 2.2 3.0 4.0
rated voltage ( v ) 220 220/380 220/380 220/380 220/380 380
frequency ( hz ) 50 50 50 50 50 50
rated speed ( r/min ) 1440 1440 1440 1440 1440 1440
noise db（a） 70 75 78 76 78 80
net weight（kg） 48 50 75 85 87 160
air tank volume（l） 50 50 90 90 90 200
overall dimension:
l * w * h （mm） 		680*450*900 680*450*900 950*450*950 800*450*900 800*450*900 1090*900*950

note: the volume of the air tank is based on the actual factory value and can be customized
